Building Wire Cable THW 300 MCM Copper Conductor 37 Strands 600V

Size of AWG: 300

Number of Strands: 37

Voltage : 600V

Number of cores: Single Core

Package : 100 Meters One Roll with Export Wooden Case & Pallet

Email: manager@hdcable.com.cn

Send message Whatsapp

Share with:

OVERVIEW STANDARD CONSTRUCTION PARAMETER

Cable THW 300 Application

The copper conductors type THW are used for power and lighting circuits in industrial, commercial and residential facilities where it is required of more security, just as it is specified in the National Electrical Code. This type of conductor can be used in dry and wet places; its maximum temperature of operation is of 75 ºC and its voltage of service for all the applications it is 600 V.

STANDARD :

Cable THW 300 Standards

• ASTM B-3: Copper Annealed or Soft Wires.
• ASTM B-8: Copper Stranded Conductors in Concentric Layers, Hard, Semi-hard or Soft.
• UL - 83: Wires and Cables Insulated with Thermoplastic Material.
• NEMA WC-5: Wires and Cables Insulated with Thermoplastic Material (ICEA S-61-402) for Transmission and Distribution of Electric Power

CONSTRUCTION :

Cable THW 300 Construction

•Single conductor copper insulated with polyvinylchloride (PVC), solid or stranded, tinned or bare soft annealed copper per ASTM B-3, B-8, B-33, and complying with the physical and electrical requirements of UL standards 83 and 1851.
• Identified by surface marking indicate manufacturers identification, conductor size, voltage rating, and UL Type TW and THW designations.

PARAMETER :
